ADC Diagnostix 720 Pocket Aneroid Sphygmomanometer-Child

Features

• Extended scaleplate graduation marks reduce parallax for easier viewing from virtually any angle.
• Adcuff Nylon Cuff with ADC’s proprietary Size Guide marking system prevents mis-cuffing.
• Adflow filter screen check and deflation valve reduces dust build-up.
• Adflow chrome-plated brass air release valve for precise deflation control.
• Meets or exceeds ANSI/AAMI/ISO 81060-1.
• Not made with natural rubber latex.
• Assembled, inspected, and packaged in the U.S.A. from foreign components.

Specifications

• Sphyg Type: Pocket.
• Gauge Product Number: #802.
• Gauge Warranty: Lifetime.
• Sphyg Accuracy: +/-3 mm Hg at 50º F (10º C) - 104º F (40º C).
• Sphyg Accuracy at Extended Temperature Range: +/- 3 mm Hg or 2%. Whichever is greater at < 50º F (10º C) and > 104º F (40º C).
• Storage Temp: -4º F (-20º C) - 131º F (55º C).
• Valve Type: ADFLOW.
• Number of Tubes: 2.
• Cuff Type: ADCUFF.
• Cuff Size: Child.
• Cuff Range: 5.1" - 7.6" (13 cm - 19.5 cm).
• Zipper Storage Case Product Number: #880.

Configurations

• 720-9CAD
• 720-9CBK
• 720-9CGR
• 720-9CGR1
• 720-9CPP

Data Sheets

ADC Diagnostix Adcuff Literature

ADC Diagnostix Aneroid Sphygmomanometer Accessories Instructions-for-Use
