Dynatronics‑D125B‑Dynatron 125 Portable Ultrasound, Each

Features

• 12 V battery (not included) powered option allows the device to travel to any location, providing ultrasound treatments immediately, wherever they are needed.
• Small and lightweight design makes it easy to carry and move around the clinic.
• Soundheads are engineered with SmartHead technology that stores calibration parameters directly inside each soundhead.
• Each unique soundhead plugged in is immediately recognized by the device and ready to use.
• Most treatments can be set up in as few as three key presses.
• Treatment time, power, frequency, or duty cycle can be modified while a treatment is in progress - without stopping the treatment.
• Selectable Duty Cycle from 10, 20, 50 percent, and Continuous.
• You can select three different frequencies without changing the soundhead. The 2 cm2, 5 cm2, and 10 cm2 soundheads each operate at 1, 2, and 3 MHz.
• Head Warming (optional): When the device is ON but idle, the soundhead is warmed automatically.

Specifications

• Weight: 4 lb.
• Dimensions: 9" (D) x 7" (W) x 4" (H).
• Power Requirements: 100 to 240 V.
• Power Consumption: 65 W.
• Fuse: 1.6 A.
• Humidity: 30 to 50%.
• Environment Temperature: 10 to 30 °C.
• Shipping Weight: 10 lb (4.54 kg).
• Shipping Dimensions: 21" x 13" x 6" (53.34 cm x 33.02 cm x 15.24 cm).

Accessories

The following accessories are compatible and commonly purchased with the Dynatron 125 Portable Ultrasound:

• #D125BAG: D125B Ultrasound Carry Bag.
• #GR573197: 12 V Battery.
• Dynatron Ultrasound Applicator Smarthead:#WSH02: 2 cm2.#WSH05: 5 cm2.#WSH10: 10 cm2.

Data Sheets

Dynatronics General Line Rehabilitation Products Guide

Dynatronics Dynatron 25 Series Brochure

Dynatronics 125 Series Portable Ultrasound Brochure
